DM24.12
Back
- 24 XLR and 8 Line analog inputs with digital gain control
- 24 XLR and 8 Line analog inputs with digital gain control
- 8 XLR and 8 Line MIX outputs
- 8 XLR and 8 Line MIX outputs
- 13 Channels 100mm motorized faders / OLED displays
- 13 Channels 100mm motorized faders / OLED displays
- 12 DCA for fader / 8 Mute Group
- 12 DCA for fader / 8 Mute Group
- USB 2-track stereo recording / playback
- 24-bit, 48 / 96KHz sampling rate
- Digital Noise Gate / Compressor & Limiter
- 7" LCD touch screen
- USB port for Presets save / load firmware update
- Digital 4-band parametric EQ and 31 segment GEQ
- Auto MIX / RTA / FBC / Talkback
- Up to 32 digital inputs / Outputs
- 2 Internal FX
- Ethernet Port connect to wireless router for iPad Remote Control APP
- * Currently not sold in all world territories
- 24-bit, 48 / 96KHz sampling rate
- Digital Noise Gate / Compressor & Limiter
- Digital 4-band parametric EQ and 31 segment GEQ
- Auto MIX / RTA / FBC / Talkback
- Ethernet Port connect to wireless router for iPad Remote Control APP
- * Currently not sold in all world territories
| Microphone input | Electronically balanced |
| Frequency Response to Main Output | 22Hz ~ 20KHz at 0dBu ±1.5dBu |
| Distortion (THD&N) to Main Output | <0.03% at 0dBu 1KHz |
| Gain | 0dBu ~ 50dBu |
| SNR (Signal to Noise Ratio) | 108dB |
| Maximum Input Level | +20dBu |
| Phantom Power (+/-3V) | +48VDC |
| Frequency Response to Main Output | 22Hz ~ 22KHz at 0dBu ±1.5dBu |
| Distortion (THD&N) to Main Output | <0.03% at 0dBu 1KHz |
| Maximum Input Level | +20dBu |
| Bus Out | Out 1-8 |
| Maximum Outputs Level | +20dBu |
| Main Outputs | |
| Maximum Output Level | +20dBu |
| Control Room Outputs | |
| Maximum Output Level | +20dBu |
| Headphone Outputs | |
| Maximum Output Level | +20dBu |
| System Crosstalk | |
| Input to Output (at 0dBu 1KHz) | <-88dBu |
| Adjacent Channels (at 0dBu 1KHz) | <-87dBu |
| Noise Gate | |
| Threshold Range | -84dBu - +19dBu |
| Attack time | 0mS ~ 250mS |
| Release time | 5mS ~ 2S |
| Compressor | |
| Threshold Range | -84dBu - +19dBu |
| Attack time | 0mS ~ 250mS |
| Release time | 5mS ~ 2S |
| Ratio | 1:1 to 40:1, inf: 1 |
| Gain | 0dB - +12dB |
| EQ | |
| Low (LowPass or LowShelf) | 20Hz ~ 20KHz ±(15dB±2dB) |
| Low Mid | 20Hz ~ 20KHz ±(15dB±2dB) |
| High Mid | 20Hz ~ 20KHz ±(15dB±2dB) |
| High (HighPass or HighShelf) | 20Hz ~ 20KHz ±(15dB±2dB) |
| Digital Audio | |
| ADC Dynamic Range | 113dB |
| DAC Dynamic Range | 113dB |
| Internal Processor | 32-bit , floating point |
| ADC bit depth | 32bit |
| DAC bit depth | 24bit |
| Main LCD | 7 inch (1024x600) |
| Channel LCD | 0.96 inch (128x64) |
| Impedances | |
| Microphone input | 6.8K Ohm |
| All output | 120 Ohm |
| Operating free-air temperature range | 0ºC ~ 40ºC |
| Storage temperature range | -20ºC ~ 45ºC |
