SPEAKERS
FLX

FLX 5

Back
Hi-Res Manual
  • POWER
  • 240W PROGRAM
  • TRANSDUCER LOW
  • 2 x 5" Woofer, 1.18" Voice Coil
  • TRANSDUCER HIGH
  • 1 x 1" Tweeter, 1" Voice Coil
System Type 5'' 2-way Passive System
Output Power 120W (CONTINUOUS), 240W (PROGRAM)
Sensitivity (1W/1M) 95dB
Maximum SPL @ 1m 115.5dB Max. (calculated)
Frequency Response 90Hz-20kHz (-10dB)
Impedance 8 ohms
Transducer Low 2 x 5'' Woofer, 1.18'' (30mm) Voice Coil
Transducer High 1 x 1'' Tweeter, 1'' (25mm) Voice Coil
Crossover Frequency 2.0kHz Passive
Dispersion(-6dB) 100° Horizontal, 12° Vertical (one module)
Attachment Points Adjustable Rigging System, Vertical Splay Adjustable in 1.5° Increments from 0°-12°
Connectors 2 x SPK4 Style
Enclosure Construction Polypropylene enclouse with side handles, steel Grille with foam
Fittings information Steel Stirrup Material, 3 Flying Points
Dimensions (HxWxD) (W) 430mm x (H) 161mm x (D) 304mm ; (W) 16.93" x (H) 6.33" x (D) 11.96"
Net Weight 8kg / 17.63 lbs
